YAG Mini Metal Laser Cutting Machine for stainless steel from China manufacturer - Wuhan Changxin Laser Technology & Development Co., Ltd.

YAG Mini Metal Laser Cutting Machine for stainless steel

Price:	1.0~19999.0 USD
Payment Terms:	T/T
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: RL-LCY500-0303/ RL-LCY500-0...

Production Capacity: 6000sets/year

Delivery Date: 30-35 working days

Laser Type: YAG

function: metal cutting

Means of Transport: Ocean

Packing: wooden case

Application: Laser Cutting

Brand Name: cxlaser

Applicable industries:
YAG laser cutting machine has been widely used in manufacture billboard, high-low voltage electric cabinet, textile machinery

Product Features

1. High precision: be suitable forcut various metal metal sheet,stainless steel, metal pipe
2. Fast speed: 100times higher than linear cutting

3. Small heat affected zone, good dimension stability. Flat and handsome laser-slotted, without later process

4. Steady performance: as a mature laser apparatus, the YAG laser cutting machine is suitable for serial production.

Application

We provide two types of precision cutting machines. One is widely applied to cut sheet material(diameter less than 2.0mm)like medical device, microelectronic element, spectacle frame ,leaf spring, artware, circuit board, electric kettle, etc. The other is widely applied to cut machine and electric accessory (diameter 2.0mm-5.0mm)

Main data

Model	RL-LCY500-0303/ RL-LCY500-0404/ RL-LCY500-0505
Processing scale	300300mm/400400mm/500*500mm
Cutting thickness	0.15-6mm
Max output power	500W
Laser wavelength	1064nm
Pulse frequency	1-300HZ
Min.linewidth	0.15mm
Electrical source	380V/50HZ/100A
X/Y/Z axis geometric positioning accuracy	≤±0.05mm/1000mm
X/Y/Z axis re-orientation accuracy	≤±0.04mm
Cooling system	5p water cooling
Max cutting speed	35mm/s
Weight	380/390/400kg
