Rotary die cutters system laser die cut machine with CE

Payment Terms: T/T
Place of Origin: Hubei, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Means of Transport: Ocean
Packing: wooden case
Application: Laser Cutting
Brand Name: Changxin
Production Capacity: 6000sets/year
Delivery Date: 10~15 days
Laser Type: CO2

Rotary die cutters system laser die cut machine
1.Accord with Europe CE standard
2.Bidirectional double laser heads
3.Cut upto 25m plywood

Rotary die cutters system laser die cut machine with CE

Product Featrue
We own an independent intellectual property rights of our laser die board making machine
Adopting imported guide rails, advanced controlling system and Changxin's special designed software
Work directly without any other gas inserted ,and remove the somke promptly to avoid the environmental pollution.
Compatible with AUTOCAD, CoreDraw, and Adobe Photoshop.
Technical Parameters
Model of Machine   CX1212
Laser Tube Type   CO2Sealed LaserTube

Laser Power    300W (work bidirectionally with two laser heads)

Cooling system   Water chiller
Cutting Speed    0-200mm/min
Valid Size     1160*1200mm
Power Supply    220V 10A
Sword Seam Breadth   0.3-3mm(optional)
Max Cutting Thickness   25mm
Color separation    Yes
Cutting precision   0.02mm
Motor Servo Motor
Transmission Ballscrew
Image Form   PLT, EPS, BMP, DXF
Air Feed Means    Air
Dimension   1760*1660*960mm/1760*2220*960mm

Optional parts
1).Up and down work table (makes the machine moves up and down automatically)
2).Rotary attachment (engrave cylinders)
3).Red light pointer (make the laser beam visible)
4).USB port (make the machine work without a computer)
Accessories
Necessary attachment like: water cooling, exhaust fan, air assist, software, English friendly user manual, data cable and other free parts.
